English The FBR-Ethernet-2 (MM / ST) is a multi-mode (MM), rugged, industrial-grade 10 / 100M Ethernet to fiber optic media converter, which provides one channel for media conversion between 10 / 100BaseTX and 100BaseFX. Besides the capability of long distance data transmission and the large carrying capacity, fiber lines are inherently resistant to EMI / RFI, lightning, transient surges and ground loops; therefore, they are ideal for data communications surrounded by heavy electrical or radio interference. This industrial Ethernet-to-Fiber-Optic converter operates within a temperature range of -40ºF to 185ºF (-40ºC to 85ºC), and features 600W surge protection and 15kV ESD static protection. It features auto-negotiation for half or full-duplex and 10 or 100Mbps data rates, and supports MDI (straight-through) and MDIX (crossover) cables, therefore, no DIP switch, jumper settings or software drivers are required, making the unit a highly reliable and truly plug-and-play device. The FBR-Ethernet-2 (MM / ST) comes with ST connectors for fiber optic links and can extend the 10 / 100M Ethernet distance to 3 miles (5 km). Thanks to the professional and unique casing design, the product can be mounted directly on a wall, panel or DIN Rail, without a need of using any unsecured DIN-Rail or wall-mount brackets. A separate external power supply is included in the package.
- Rugged industrial-grade 10 / 100M Ethernet to fiber optic converter.
- Converts 10 or 100M Ethernet to Optical Fiber Signals and vice versa.
- Transmits 10 / 100M Ethernet data over a long distance through fiber optic cables (multi-mode: 3 miles or 5 km).
- External 9 to 30V DC powered (included).
- Industrial grade enclosed in a rugged, rustless ABS housing.
- Direct DIN-Rail (Rack) or Wall / Panel mounting (stackable).
- Auto-negotiation of speed and duplex mode on TX port.
- Auto-MDIX on TX port.
- Store-and-forward mechanism.
- LED indications.
- Multi-mode with ST connectors.
- Supports a wide range of fiber optic cables.
- Operating temperature: -40ºF to 185ºF (-40ºC to 85ºC).
- Built-in 600W surge protection, 15kV static protection and circuit protection.
- Surface Mount Technology manufactured to RoHS and ISO-9001 standards.
- Safety: Strictly certified by TUV (Cert No. SG-CE-100005; SG-FCC-100002).
- 5-year manufacturer's warranty.
