| Transmission distance | 0~1800m |
| Signal Type | Video(PAL, NTSC, SECAM and other baseband video signal) |
| Power Supply Input | 100~265V AC, 50/60Hz, 200mA |
| Connector | 8 x Coaxial BNC(female), 2 x 8-Pin twisted-pair terminal, 2 x RJ45, AC power outlet with double insurance tube |
| Surge Protection | 6000V 10uS*700uS IEC61000-4-5 |
| Frequency response | DC-8MHz |
| CMRR | 0 to 8MHz 60dB (typical) |
| Impedance | Coax (BNC female) 75 Ohm; UTP (unshielded twisted pair) 100 ohms |
| Cable Type | Cat5 or Cat5e unshielded twisted pair |
| Cable Impedance | 100 ± 20 ohms |
| Distributed capacitance | less than 62pF/m |
| DC loop resistance | 18 Ohm/100m |
| Operating temperature | -20oC~70oC |
| Relative Humidity | 0~95%(non-condensing) |
| Storage temperature | -40oC~150oC |
| Dimension | 432mm x 97mm x 44mm(fit for standard 19" 1U chassis) |
| Net Weight | 1200g |
